BV421 Rat Anti-Mouse CD105
BV421 Rat Anti-Mouse CD105
Flow cytometric analysis of CD105 expressed on mouse bEnd.3 cell line. Mouse bEnd.3 cells (ATCC# CRL-2299) were stained with either BD Horizon™ BV421 Rat Anti-Mouse CD105 antibody (Cat. No. 562760, solid line histogram) or BD Horizon™ BV421 Rat IgG2a, κ Isotype Control (Cat. No. 562602; dashed line histogram). Flow cytometric fluorescence histograms were derived from gated events with the forward and side light-scatter characteristics of viable cells. Flow cytometry was performed using a BD™ LSR II Flow Cytometer System.
Flow cytometric analysis of CD105 expressed on mouse bEnd.3 cell line. Mouse bEnd.3 cells (ATCC# CRL-2299) were stained with either BD Horizon™ BV421 Rat Anti-Mouse CD105 antibody (Cat. No. 562760, solid line histogram) or BD Horizon™ BV421 Rat IgG2a, κ Isotype Control (Cat. No. 562602; dashed line histogram). Flow cytometric fluorescence histograms were derived from gated events with the forward and side light-scatter characteristics of viable cells. Flow cytometry was performed using a BD™ LSR II Flow Cytometer System.
製品詳細
Down Arrow Up Arrow


BD Horizon™
Endoglin; Edg; EGLN; Eng; MJ7/18 antigen; S-endoglin
Mouse (QC Testing)
Rat IgG2a, κ
Mouse skin (inflamed)
Flow cytometry (Routinely Tested)
0.2 mg/ml
13805
AB_2734710
Aqueous buffered solution containing BSA and ≤0.09% sodium azide.
RUO


Preparation and Storage

Store undiluted at 4°C and protected from prolonged exposure to light. Do not freeze. The monoclonal antibody was purified from tissue culture supernatant or ascites by affinity chromatography. The antibody was conjugated with BD Horizon BV421 under optimum conditions, and unconjugated antibody and free BD Horizon BV421 were removed.

Product Notices

  1. Since applications vary, each investigator should titrate the reagent to obtain optimal results.
  2. Source of all serum proteins is from USDA inspected abattoirs located in the United States.
  3. An isotype control should be used at the same concentration as the antibody of interest.
  4. Please refer to www.bdbiosciences.com/us/s/resources for technical protocols.
  5. Caution: Sodium azide yields highly toxic hydrazoic acid under acidic conditions. Dilute azide compounds in running water before discarding to avoid accumulation of potentially explosive deposits in plumbing.
  6. For fluorochrome spectra and suitable instrument settings, please refer to our Multicolor Flow Cytometry web page at www.bdbiosciences.com/colors.
  7. Brilliant Violet™ 421 is a trademark of Sirigen.
  8. Pacific Blue™ is a trademark of Molecular Probes, Inc., Eugene, OR.
562760 Rev. 1
抗体の詳細
Down Arrow Up Arrow
MJ7/18

The MJ7/18 monoclonal antibody specifically binds to mouse CD105 (also known as endoglin) which is a homodimer of 90-kDa subunits and is predominantly expressed on vascular endothelial cells.  High levels of mouse endoglin mRNA have been reported to be detectable in the ovary, uterus, NCTC-2071 fibroblasts, and to a lesser extent, in heart, muscle and stromal cells in connective tissue of various organs.  Endoglin has been reported to play an essential role in embryonic angiogenesis.  Both mouse and human endoglin display strong amino-acid sequence homology to the transmembrane and cytoplasmic regions of the type III TGF-ß receptor.

The antibody was conjugated to BD Horizon™ BV421 which is part of the BD Horizon™ Brilliant Violet™ family of dyes. With an Ex Max of 407-nm and Em Max at 421-nm, BD Horizon™ BV421 can be excited by the violet laser and detected in the standard Pacific Blue™ filter set (eg, 450/50-nm filter). BD Horizon™ BV421 conjugates are very bright, often exhibiting a 10 fold improvement in brightness compared to Pacific Blue™ conjugates.

562760 Rev. 1
フォーマットの詳細
Down Arrow Up Arrow
BV421
The BD Horizon Brilliant Violet™ 421 (BV421) Dye is part of the BD Horizon Brilliant Violet™ family of dyes. This polymer-technology based dye has an excitation maximum (Ex Max) of 407-nm and an emission maximum (Em Max) at 423-nm. Driven by BD innovation, BV421 is designed to be excited by the violet laser (405-nm) and detected using an optical filter centered near 420-nm (e.g., a 431/28-nm or 450/50-nm bandpass filter). BV421 is an ideal alternative for V450 as it is approximately ten times brighter with less spillover into the BV510/V500 detector. Please ensure that your instrument’s configurations (lasers and optical filters) are appropriate for this dye.
altImg
BV421
Violet 405 nm
407 nm
423 nm
562760 Rev.1
引用&参考文献
Down Arrow Up Arrow

Development References (3)

  1. Ge AZ, Butcher EC. Cloning and expression of a cDNA encoding mouse endoglin, an endothelial cell TGF-beta ligand. Gene. 1994 January; 138(1-2):201-206. (Immunogen). View Reference
  2. Li DY, Sorensen LK, Brooke BS. Defective angiogenesis in mice lacking endoglin. Science. 1999; 284(5419):1534-1537. (Biology). View Reference
  3. St-Jacques S, Cymerman U, Pece N, Letarte M. Molecular characterization and in situ localization of murine endoglin reveal that it is a transforming growth factor-beta binding protein of endothelial and stromal cells. Endocrinology. 1994 June; 134(6):2645-2657. (Biology). View Reference
562760 Rev. 1

Please refer to Support Documents for Quality Certificates


Global - Refer to manufacturer's instructions for use and related User Manuals and Technical data sheets before using this products as described


Comparisons, where applicable, are made against older BD Technology, manual methods or are general performance claims.  Comparisons are not made against non-BD technologies, unless otherwise noted.

For Research Use Only. Not for use in diagnostic or therapeutic procedures.
