PE Mouse Anti-Human HLA-DR
Product Details
Down Arrow Up Arrow


BD™
MHC class II antigen; HLA class II histocompatibility antigen
Human
Mouse IgG2a, κ
Human lymphoblastoid B-cell line RPMI 8866
Flow cytometry
12.5 μg/mL
20 μL
Phosphate buffered saline with gelatin and 0.1% sodium azide.
RUO (GMP)


Preparation And Storage

Store vials at 2° to 8°C. Conjugated forms should not be frozen and should be protected from exposure to light. Each reagent is stable for the period shown on the bottle label when stored as directed.

347367 Rev. 1
Antibody Details
Down Arrow Up Arrow
L243

The Anti-HLA-DR antibody, clone L243, is derived from the hybridization of NS-1/1-Ag4 mouse myeloma cells with spleen cells isolated from BALB/c mice immunized with the human lymphoblastoid B-cell line RPMI 8866.

The Anti-HLA-DR antibody recognizes a human class II major histocompatibility complex (MHC) antigen. The antigen is a transmembrane glycoprotein composed of α- and β-subunits that have molecular weights of 36 and 27 kilodaltons (kDa), respectively.

347367 Rev. 1
Format Details
Down Arrow Up Arrow
PE
R-Phycoerythrin (PE), is part of the BD family of Phycobiliprotein dyes. This fluorochrome is a multimeric fluorescent phycobiliprotein with excitation maximum (Ex Max) of 496 nm and 566 nm and an emission maximum (Em Max) at 576 nm. PE is designed to be excited by the Blue (488 nm), Green (532 nm) and Yellow-Green (561 nm) lasers and detected using an optical filter centered near 575 nm (e.g., a 575/26-nm bandpass filter). As PE is excited by multiple lasers, this can result in cross-laser excitation and fluorescence spillover on instruments with various combinations of Blue, Green, and Yellow-Green lasers. Please ensure that your instrument’s configurations (lasers and optical filters) are appropriate for this dye.
altImg
PE
Yellow-Green 488 nm, 532 nm, 561 nm
496 nm, 566 nm
576 nm
347367 Rev.1
Citations & References
Down Arrow Up Arrow
View product citations for antibody "347367" on CiteAb

Development References (16)

  1. Brodsky FM. A matrix approach to human class II histocompatibility antigens: reactions of four monoclonal antibodies with the products of nine haplotypes.. Immunogenetics. 1984; 19(3):179-94. (Biology). View Reference
  2. Edwards JA, Durant BM, Jones DB, Evans PR, Smith JL. Differential expression of HLA class II antigens in fetal human spleen: relationship of HLA-DP, DQ, and DR to immunoglobulin expression.. J Immunol. 1986; 137(2):490-7. (Biology). View Reference
  3. Engleman EG, Warnke R, Fox RI, Dilley J, Benike CJ, Levy R. Studies of a human T lymphocyte antigen recognized by a monoclonal antibody.. Proc Natl Acad Sci USA. 1981; 78(3):1791-5. (Biology). View Reference
  4. Grouard G, Durand I, Filgueira L, Banchereau J, Liu YJ. Dendritic cells capable of stimulating T cells in germinal centres.. Nature. 1996; 384(6607):364-7. (Biology). View Reference
  5. Lampson LA, Levy R. Two populations of Ia-like molecules on a human B cell line.. J Immunol. 1980; 125(1):293-9. (Biology). View Reference
  6. Levacher M, Tallet S, Dazza MC, Dournon E, Rouveix B, Pocidalo JJ. T activation marker evaluation in ARC patients treated with AZT. Comparison with CD4+ lymphocyte count in non-progressors and progressors towards AIDS.. Clin Exp Immunol. 1990; 81(2):177-82. (Biology). View Reference
  7. O'Doherty U, Peng M, Gezelter S, et al. Human blood contains two subsets of dendritic cells, one immunologically mature and the other immature.. Immunology. 1994; 82(3):487-93. (Biology). View Reference
  8. Robbins PA, Evans EL, Ding AH, Warner NL, Brodsky FM. Monoclonal antibodies that distinguish between class II antigens (HLA-DP, DQ, and DR) in 14 haplotypes.. Hum Immunol. 1987; 18(4):301-13. (Biology). View Reference
  9. Stites DP, Casavant CH, McHugh TM, et al. Flow cytometric analysis of lymphocyte phenotypes in AIDS using monoclonal antibodies and simultaneous dual immunofluorescence.. Clin Immunol Immunopathol. 1986; 38(2):161-77. (Biology). View Reference
  10. Terstappen LW, Hollander Z, Meiners H, Loken MR. Quantitative comparison of myeloid antigens on five lineages of mature peripheral blood cells. J Leukoc Biol. 1990; 48(2):138-148. (Biology). View Reference
  11. Thomas R, Lipsky PE. Human peripheral blood dendritic cell subsets. Isolation and characterization of precursor and mature antigen-presenting cells.. J Immunol. 1994; 153(9):4016-28. (Biology). View Reference
  12. Tomkinson BE, Wagner DK, Nelson DL, Sullivan JL. Activated lymphocytes during acute Epstein-Barr virus infection.. J Immunol. 1987; 139(11):3802-7. (Biology). View Reference
  13. Warnke R, Miller R, Grogan T, Pederson M, Dilley J, Levy R. Immunologic phenotype in 30 patients with diffuse large-cell lymphoma.. N Engl J Med. 1980; 303(6):293-300. (Biology). View Reference
  14. Warnke RA, Levy R. Detection of T and B cell antigens with hybridoma monoclonal antibodies: a biotinavidin-horseradish peroxidase method. J Histochem Cytochem. 1980; 28:771-776. (Biology).
  15. Zipf RF, Fox R, Dilley J, Levy R. Definition of the high risk ALL patient by immunologic phenotyping withmonoclonal antibodies. Cancer Res. 1981; 41:4786. (Biology).
  16. van Es A, Baldwin WM, Oljans PJ, Tanke HJ, Ploem JS, van Es LA. Expression of HLA-DR on T lymphocytes following renal transplantation, and association with graft-rejection episodes and cytomegalovirus infection.. Transplantation. 1984; 37(1):65-9. (Biology). View Reference
View All (16) View Less
347367 Rev. 1



Please refer to Support Documents for Quality Certificates


Global - Refer to manufacturer's instructions for use and related User Manuals and Technical data sheets before using this products as described


Comparisons, where applicable, are made against older BD Technology, manual methods or are general performance claims.  Comparisons are not made against non-BD technologies, unless otherwise noted.

For Research Use Only. Not for use in diagnostic or therapeutic procedures.



Although not required, these products are manufactured in accordance with Good Manufacturing Practices.
